Spec.
|
Parameter
|
|
Battery Energy Storage Data
|
|
Battery Cell
Spec.
|
LithiumLFP, 3.2V,
314Ah, 0.5C, Cycle Life: 12,000 cycles
|
|
Battery
Module/Rack
|
1P16S,
51.2V,16.1KW / 1P13S 665.6V, 209KW
|
|
Max. Charging&Discharging
Power/Current
|
110KW/200A
|
|
Operating Voltage
Range
|
520V～760V (Acceptable
Range: 250V～820V)
|
|
Depth of
Discharge (DOD)
|
99%
|
|
Cell Energy
Efficiency
|
95%
|
|
DC/DC Converter
|
2*50kW
|
|
Input PV
|
|
Max Input Power
|
2*50kW
|
|
Max PV Open
Circuit/ MPPT Voltage Range
|
900V/ 180V～800V
|
|
MPPT Quantity
|
2
|
|
ACSide
|
|
Grid Connection
|
3P3W/3P4W , 50Hz
|
|
Rated Output
Capacity
|
125kVA
|
|
Max. Output
Capacity
|
137.5kVA
|
|
Max. Grid Input
Capacity
|
250kVA
|
|
Max. Input
Current/Max.Output Current
|
360A/ 180A
|
|
Overload
Capability
|
110% Long term
|
|
Power Factor
|
0.99
|
|
PCS Max
Efficiency
|
98.5%
|
|
STS unit
|
250KVA,
On/off-grid switching time<10ms, Max. efficiency 99.5%
|
|
SystemParameters
|
|
Features &
Protection
|
Fire Detection and Protection, Anti-IslandingProtection,DCReversePolarityProtection,InsulationDetection,DCSurgeProtection,
AC Surge Protection, DC Short Circuit Protection, AC Overcurrent Protection,
AC Short Circuit Protection, and AC Under/Over Voltage Protection
|
|
Operating
Temperature
|
-30℃～60℃
|
|
Communication
Method
|
Ethernet/4G/RS485/CAN
|
|
Cabinet Encloser
Protection
|
IP54
|
|
Cooling Method
|
5KW Intelligent
Air Cooling
|
|
Operating
Humidity/ Altitude
|
0~95%RHNon-Condensing/
4000m
|
|
Dimension (W*D*H)
[mm]
|
1690 ×1000×2230
|
