● saving the useful unit space within the rack (Zero Unit)

● 24 output ports (C13 & C19)

● 2 cable braces that could be mounted on PDU

● 2 brackets used for mounting and installing different components on the unit rail

● 2 16A fuses (Siemens brand)

● A three-prong industrial plug and 3x6m Afshan cable
● Vertically installable on the front and back side of the rack

Model Specification	IPC Basic PDU	IPC Metered PDU		IPC IP-Based PDU
Rack Space to accupy	Zero Unit	Zero Unit	1Unit(19")	Zero Unit	1Unit(19")
Mounting	Vertical	Vertical	Horizontal	Vertical	Vertical
Outlet Connections	C13(IEC320)20 C19(IEC320)4	C13(IEC320)20 C19(IEC320)4	C13(IEC320)*8	C13(IEC320)20 C19(IEC320)4	C13(IEC320)*8
Cord Type	6*3 mm2	6*3 mm2	1.5*2 mm2	6*3 mm2	1.5*2 mm2
Cord Length(m)	2
Input Connection	IP 44(P+N+G) IEC60309

Features	Using fuse for shortcircuit & overload protection Earthed outlets
	------	LCD for displaying current, voltage & power
	------	------	------	Remote monitoring and controling of IP-PDU,s parameters over Ethernet(via SNMP) Sending alarms information to defined E-Mail addresses Setting maximum load current Managing PDU over Ethernet
Dimension (mm)(WHD)	44161956	44161956	20044.4482.6	44161956	20044.4482.6
Voltage input	200-240V AC 50-60Hz
Maximum Load current(A)	32
