Electrical Characteristics of UniMix Medium Voltage Switchgear

Rated Voltage

KV

12

17.5

24

Power Frequency Test

KV/min

28

38

50

Impulse withstand Voltage

KV

75

95

125

Main Current of Branch Connections

A

400-630-800-1250

Rated Current of Branch Connections

A

- Circuit Breakers

630-1250

630-1250

630-1250

- Switch Disconnectors

400-630

400-630

400-630

- Isolators

400-630

400-630

400-630

Rated Short-time Withstand Current

KA/1S

12.5-16

20

25

KA/3S

12.5

16

20

Peak Current

KV

31.5-40

50

63

Dimensions of The Panel

Dimensions

width

height

depth

Unit =mm

375-500-750

1950

975
